Aprašymas

Camera
Image Sensor: 1 / 2.7 „CMOS
Image Size: 2592 × 1944
Electronic Shutter: 1 s ~ 1 / 100000 s
Iris Type: Fixed Iris
Min. Illumination: 0 lux (LED ON)
S/N Ratio: ?50dB
Lens: 2.8 mm@F1.0, horizontal FoV: 94.8°; vertical FoV: 78.4°; diagonal FoV:107.3°
Focus: Fixed
Lens Mount: M12
Day & Night: ICR
Wide Dynamic Range: 120dB
BLC: Yes
HLC: Yes
Defog: Yes
Digital NR: 3D DNR
Angle Adjustment: Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360°
Video Compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
H.264 Compression Standard: Baseline Profile/Main Profile/High Profile
Resolution: 5MP (2592×1944 ), 4MP (2592×1520), 2K (2560×1440), 3MP(2304×1296 ),1080P (1920×1080), 720P (1280×720 ), D1, CIF, 480×240
Main Stream: 5MP/4MP/2K/3MP/1080P / 720P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )
Sub Stream: 720P/D1/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )
Third Stream: D1/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )
Bit Rate: 64 Kbps ~ 8 Mbps
Bit Rate Type: VBR / CBR
Audio Compression: G711A / U
Image Settings: ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, NR,etc. adjustable through client software or web browser
ROI: Each ROI to be configured separately
Interfaces
Network: RJ45
Video Output: No
Audio: 1CH audio input
Storage: Built-in micro SD card slot; up to 256GB
Reset: Yes
Alarm: No
Intelligent Analytics (Smart Events)
Perimeter Protection: Line crossing, intrusion (human/motor vehicle/non-motor vehicle classification)
Target Counting Line crossing human/motor vehicle/non-motor vehicle counting
Exception Detection: Scene change, video blur and video color cast detection
Face Detection: Face detection and face capture
Functions
Remote Monitoring: Web browsing,CMS remote control
Online Connection: Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission
Network Protocol: UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, ICMP, IGMP, PPPoE, DDNS, SMTP, FTP, SNMP,HTTP, 802.1x, UPnP, HTTPs, QoS
Interface Protocol: ONVIF
Storage: Network remote storage; micro SD card storage up to 256GB
Smart Alarm: Motion detection, SD card error, SD card full
General Function: Watermark, IP address filtering, video mask, heartbeat, illegal login lock,
PoE: Yes , IEEE802.3af
White Light Range: 20~30 m
Ingress Protection: IP67
Others
Power Supply: DC12V/PoE
Power Consumption: < 7W
Operating Environment: – 30 °C ~ 60 °C (-22°F~140°F)
Humidity: less than 95 % (non-condensing)
Dimensions ( mm ): 217.8 × 80.5 × 80.3
Weight ( net ): Approx. 0.68KG
Installation: Ceiling mounting; Wall mounting
Certificate: CE, FCC
Environmental Protection: Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
Junction box: IPT VSB12D, VSB IPT9D
